Tq-007Air dryer filter

PROTECTION AND RELIABILITY

Compressed air can be contaminated by dirt, water and oil, which can damage the downstream appliances.DEMARGO thanks to its 15 years experience in this sector offers a wide range of in-line filters for removing these contamination and protecting the equipment served by compressed air, according to the ISO 8573-1 standards.

Working conditions and Technical Data

Capacity:1.2~25m³/min

Max. Working Pressure:16 bar. Max.working temperature:80℃

Differential Pressure: 0.07 bar

Filter Element Service: 6000 hours

Air Filter With Differential Pressure Indicator

Filter housing internal with anti-corrosion treatment.

Features

1、Generous aerodynamic flow paths and edged ports for reducing pressure drops.

2、Differential pressure gauges are the Simple Way to Check a Filter Status.It helps the user to determine when to replace the filter element. DEMARGO in standard designs with higher temperature and increased corrosion resistance.

3、The facilitates the element replacement by reducing service

clearance, and the absence of tie-rod contributes in precious gain for the flow path through the end cap collar.

4、Cataphoretic coating confers high quality surface finish as well as ensure long high protection against corrosion.

5、 Filter elements are characterized by:

* high-quality stainless steel cores ensure extreme strength

* Endcaps made of synthetic material resistant up to 120 C, ensuring absolutely corrosion free solution

* Outer drainer made of Strong alloy materialthat make drainage more timely and durable.

6、 Outer drainer made of Strong alloy material that make drainage more timely and durable.

Guaranteed Air Purity Elements

High-efficient glass fiber and stainless steel

No risks of cracked filter media, cilinder implosion, top cap leakages or oil re- entrainment

Stainless steel cores guarantee ultimate strength

Protection paper to avoid damaging of glass fiber media

The filter housings are completely cleanon the inside and outside and externally painted afterwards.Special coating ensures a housing lifetime of at least 20 years

Applicable Industries

The DEMARGO TQ-007 Refrigerated Air Dryer Filter is widely used across various industries that require reliable, clean compressed air:

Hotels – HVAC systems, pneumatic controls, laundry equipment

Clothing Stores – Garment pressing, air curtain systems

Building Material Stores – Pneumatic conveying, cutting tools

Manufacturing Plants – Factory automation, general workshop air

Food & Beverage Factories – Hygienic air for processing, packaging, and conveying

Farms – Ventilation systems, pneumatic feeding equipment

Restaurants – Kitchen ventilation, pneumatic controls

Construction Works – Pneumatic tools, dust suppression systems

Energy & Mining – Instrument air, process control systems

Food & Beverage Shops – Packaging equipment, dispensing systems

Advertising Companies – Printing presses, pneumatic actuators
